Agri Drip Irrigation System 16m Plastic Drip Tape with 20 cm Spacing 1 Hectare Drip Irrigation Layout Buy Drip Tape
Double Hole Layflat Drip Tape
$0.01-$0.04/meters
Lock Nut Drip Tape Connector
$0.15-$0.1/pieces
Drip Tape Mini Valve
$0.1-$0.3/pieces
Hole Punch
$4-$11/pieces
LDPE Irrigation Pipe
$0.09-$0.3/meters
PVC Ball Valve for Main Pipe
$5-$15/pieces
$5-$15/pieces
Products Introduction
Specifications of Single Hole-Virgin Material
Product Code |
Diameter |
Wall Thickness (mm) |
Dripper Spacing |
Flow Rate(L/H) |
Working Pressure (Bar) |
Roll Length |
PRDT011601510010 |
16mm |
0.15mm |
10cm |
0.8, 1.1,1.38, 2.0, 3.0L/H |
0.8 |
1000m |
PRDT011601515010 |
0.15mm |
15cm |
0.8 |
1000m |
||
PRDT011601520010 |
0.15mm |
20cm |
0.8 |
1000m |
||
PRDT011601520020 |
0.15mm |
20cm |
0.8 |
2000m |
||
PRDT011601525010 |
0.15mm |
25cm |
0.8 |
1000m |
||
PRDT011601525020 |
0.15mm |
25cm |
0.8 |
2000m |
||
PRDT011601530010 |
0.15mm |
30cm |
0.8 |
1000m |
||
PRDT011601530020 |
0.15mm |
30cm |
0.8 |
2000m |
||
PRDT011601810010 |
0.18mm |
10cm |
1 |
1000m |
||
PRDT011601815010 |
0.18mm |
15cm |
1 |
1000m |
||
PRDT011601815020 |
0.18mm |
15cm |
1 |
2000m |
||
PRDT011601820010 |
0.18mm |
20cm |
1 |
1000m |
||
PRDT011601820020 |
0.18mm |
20cm |
1 |
2000m |
||
PRDT011601825010 |
0.18mm |
25cm |
1 |
1000m |
||
PRDT011601825020 |
0.18mm |
25cm |
1 |
2000m |
||
PRDT011601830010 |
0.18mm |
30cm |
1 |
1000m |
||
PRDT011601830020 |
0.18mm |
30cm |
1 |
2000m |
||
PRDT011602010010 |
0.20mm |
10cm |
1 |
1000m |
||
PRDT011602015010 |
0.20mm |
15cm |
1 |
1000m |
||
PRDT011602015020 |
0.20mm |
15cm |
1 |
2000m |
||
PRDT011602020010 |
0.20mm |
20cm |
1 |
1000m |
||
PRDT011602020020 |
0.20mm |
20cm |
1 |
2000m |
||
PRDT011602025010 |
0.20mm |
25cm |
1 |
1000m |
||
PRDT011602025020 |
0.20mm |
25cm |
1 |
2000m |
||
PRDT011602030010 |
0.20mm |
30cm |
1 |
1000m |
||
PRDT011602030020 |
0.20mm |
30cm |
1 |
2000m |
||
PRDT011602515020 |
0.25mm |
15cm |
1 |
2000m |
||
PRDT011602520020 |
0.25mm |
20cm |
1 |
2000m |
||
PRDT011602530020 |
0.25mm |
30cm |
1 |
2000m |
||
PRDT011602540020 |
0.25mm |
40cm |
1 |
2000m |
||
PRDT011603015015 |
0.30mm |
15cm |
1 |
1500m |
||
PRDT011603020015 |
0.30mm |
20cm |
1 |
1500m |
||
PRDT011603030015 |
0.30mm |
30cm |
1 |
1500m |
||
PRDT011603040015 |
0.30mm |
40cm |
1 |
1500m |
||
PRDT011604015010 |
0.40mm |
15cm |
1 |
1000m |
||
PRDT011604020010 |
0.40mm |
20cm |
1 |
1000m |
||
PRDT011604030010 |
0.40mm |
30cm |
1 |
1000m |
||
PRDT011604040010 |
0.40mm |
40cm |
1 |
1000m |
Feature
1) Made by 100% vigin Polyethylene.
2) The actual meter of one roll is produced longer than the label stated.
3) No breakage for every roll, good for drip tape laying out by machinery.
4) Safe cohesion of flat emitter.
5) Production is strictly controlled in conformity with standard ISO 9261:2004. Inspection is carried out on diameter, wall thickness, emitter spacing, flow rate, bursting pressure, CV, Emission Uniformity, Carbon Black content, Hydrostatic pressure, tensile strength.
2) The actual meter of one roll is produced longer than the label stated.
3) No breakage for every roll, good for drip tape laying out by machinery.
4) Safe cohesion of flat emitter.
5) Production is strictly controlled in conformity with standard ISO 9261:2004. Inspection is carried out on diameter, wall thickness, emitter spacing, flow rate, bursting pressure, CV, Emission Uniformity, Carbon Black content, Hydrostatic pressure, tensile strength.
Specifications and sizes can be customized as needed
Company Profile
FAQ
Manufacturer or trading company? |
We are a professional manufacturer of agricultural micro irrigation products. Welcome to visit our factory. |
||||||
Delivery time |
Sample:1-7 days; LCL order: 7-15 days;
FCL order: 15-20 days;
OEM & ODM order: on a case-by-case basis.
|
||||||
Terms of payment |
30% paid in advance by T/T as deposit, and 70% paid against scan copy of B/L by T/T as balance;
For small order, 100% paid in advance to save transaction cost.
|
||||||
Packing |
Round package and side package |
||||||
Certification |
ISO9001:2015, Alibaba Gold Plus Supplier Assessment, BV and SGS inspection. Other certification, such as SONCAP when ship to Nigeria, COC when ship to Morocco, etc.
|
||||||
Sample |
We could supply you sample for free, you only need to bear air express freight. |
||||||
OEM and ODM service |
OEM and ODM are available. |
||||||
Mode of transport |
We can delivery the goods by sea, by air, air express or train. If the volume is less than 1CBM, sea freight will not be recommended.
|
||||||
How to solve quality problem after customer received goods |
You need to send us unqualified products quantity, photos/videos and invoice number to check the problem. If necessary, you need to send back some representative samples to us.
Once the problem been confirmed by our after-sale team, we will give you a satisfied solution.
|
||||||
